Listing 1: 导入所需的 Python 库，尤其是阅读 cdf file 的库 cdflib

import glob
import numpy as np
import xarray as xr

import cdflib
from cdflib import xarray

print('CDFlib Version\n{}'.format(cdflib.__version__))

Listing 2: 指定 cdf file 的路径，将其读取为 xarray

# CDF File
filename = glob.glob(r'D:\下载的文件\PKU\专业课\科研\本科毕业论文\mms_data\mms3\mec\srvy\l2\epht89d\2021\02\mms3_mec_srvy_l2_epht89d_20210205_v2.0.1.cdf')[0]
print('Filename \n{}'.format(filename))

# Read CDF [Method #2: Xarray]
cdf2 = xarray.cdf_to_xarray(filename, to_unixtime=True, fillval_to_nan=True)
print('\nRead Type: Xarray \n{}'.format(type(cdf2)))

Listing 3: 将 Epoch 时间转换为 datetime64 格式，一会儿会用到

from typing import Any, Union
from numpy.typing import NDArray

def unix2datetime64(time: Union[list[float], NDArray[Any]]) -> NDArray[np.datetime64]:
    r"""Converts unix time to datetime64 in ns units.

    Parameters
    ----------
    time : numpy.ndarray
        Time in unix format.

    Returns
    -------
    time_datetime64 : numpy.ndarray
        Time in datetime64 format.

    Raises
    ------
    TypeError
        If time is not a list or numpy.ndarray.

    See Also
    --------
    pyrfu.pyrf.datetime642unix

    """
    # Check input type
    if isinstance(time, (list, np.ndarray)):
        time_array = np.array(time)
    else:
        raise TypeError("time must be list or numpy.ndarray")

    # Make sure that time is in ns format
    time_unix = (time_array * 1e9).astype(np.int64)

    # Convert to unix
    time_datetime64 = time_unix.astype("datetime64[ns]")

    return time_datetime64

time_epoch = cdf2['Epoch'].data
time = unix2datetime64(time_epoch)

Listing 4: 打印 cdf file 中包含的信息条目，便于寻找所需的 variable

# CDF Summary [Method #2: Xarray]
print('CDF Summary\n{}'.format(cdf2.info))

# Individual Global Variables
print('\n\nIndividual Global Variables')
for variable in cdf2.attrs:
    print('{}: {}\n'.format(variable, cdf2.attrs[variable]))

Listing 5: 读取四元数所在的 variable: 从 eci 坐标系转到 gse 坐标系

# Access Variable Data
variable = 'mms3_mec_quat_eci_to_gse'
data = cdf2[variable].data
print('\n{}\n{}\n{}'.format(variable,data,data.shape))

# Euler parameters
eci_to_gse_0 = data[:,3]
eci_to_gse_1 = data[:,0]
eci_to_gse_2 = data[:,1]
eci_to_gse_3 = data[:,2]

# 保存为 dataset 格式
eci_to_gse = xr.Dataset(
  coords=dict(
      time=time
  ),
  data_vars=dict(
      e0=(["time"], eci_to_gse_0),
      e1=(["time"], eci_to_gse_1),
      e2=(["time"], eci_to_gse_2),
      e3=(["time"], eci_to_gse_3)
  ),
  attrs=dict(
      description="Euler parameters from eci to gse"
  )
)

Listing 6: 读取四元数所在的 variable: 从 eci 坐标系转到 bcs

# Access Variable Data
variable = 'mms3_mec_quat_eci_to_bcs'
data = cdf2[variable].data
print('\n{}\n{}\n{}'.format(variable,data,data.shape))

# Euler parameters：逆变换所用的单位四元数等于正变换所用的单位四元数的共轭
bcs_to_eci_0 = data[:,3]
bcs_to_eci_1 = -data[:,0]
bcs_to_eci_2 = -data[:,1]
bcs_to_eci_3 = -data[:,2]

# 保存为 dataset 格式
bcs_to_eci = xr.Dataset(
    coords=dict(
        time=time
    ),
    data_vars=dict(
        e0=(["time"], bcs_to_eci_0),
        e1=(["time"], bcs_to_eci_1),
        e2=(["time"], bcs_to_eci_2),
        e3=(["time"], bcs_to_eci_3)
    ),
    attrs=dict(
        description="Euler parameters from eci to bcs"
    )
)

Listing 7: 四元数相乘：从 bcs 转动到 gse 坐标系；四元数乘法不对易，因此要注意相乘的顺序

# 旋转的合成：四元数乘法 —— 注意相乘的顺序
# 四元数乘法可以用 Mathematica 计算
bcs_to_gse_0 = bcs_to_eci_0 * eci_to_gse_0 - bcs_to_eci_1 * eci_to_gse_1 - bcs_to_eci_2 * eci_to_gse_2 - bcs_to_eci_3 * eci_to_gse_3
bcs_to_gse_1 = eci_to_gse_0 * bcs_to_eci_1 + eci_to_gse_1 * bcs_to_eci_0 + eci_to_gse_2 * bcs_to_eci_3 - eci_to_gse_3 * bcs_to_eci_2
bcs_to_gse_2 = eci_to_gse_0 * bcs_to_eci_2 - eci_to_gse_1 * bcs_to_eci_3 + eci_to_gse_2 * bcs_to_eci_0 + eci_to_gse_3 * bcs_to_eci_1
bcs_to_gse_3 = eci_to_gse_0 * bcs_to_eci_3 + eci_to_gse_1 * bcs_to_eci_2 - eci_to_gse_2 * bcs_to_eci_1 + eci_to_gse_3 * bcs_to_eci_0

# 保存为 dataset 格式
bcs_to_gse = xr.Dataset(
  coords=dict(
      time=time
  ),
  data_vars=dict(
      e0=(["time"], bcs_to_gse_0),
      e1=(["time"], bcs_to_gse_1),
      e2=(["time"], bcs_to_gse_2),
      e3=(["time"], bcs_to_gse_3)
  ),
  attrs=dict(
      description="Euler parameters from bcs to gse"
  )
)

# 保存所得 dataset 至他处，便于下一步使用
data_to_write = np.column_stack(((time - time[0]).astype('float64') / 1e9, bcs_to_gse_0, bcs_to_gse_1, bcs_to_gse_2, bcs_to_gse_3))
np.save('quat_bcs_to_gse.npy', data_to_write)
